A9500C

Longsung A9500C is one of the smallest LTE Cat.1 modules in LCC castellation packaging with the compact size of 24.0 × 26.0 × 2.5mm, ultra low power consumption and extended temperature range.

Designed for use in LTE network. The A9500C enables connect to the Internet at DL data speed up to 10Mbps and UL data speed up to 5Mbps.

2088

分享
  • 产品概述
  • 产品特性
  • 相关下载

Longsung A9500C is one of the smallest LTE Cat.1 modules in LCC castellation packaging with the compact size of 24.0 × 26.0 × 2.5mm, ultra low power consumption and extended temperature range.

Designed for use in LTE network. The A9500C enables connect to the Internet at DL data speed up to 10Mbps and UL data speed up to 5Mbps.

To save space on the application platform, A9500C comes as an extremely slim and compact module. This makes it ideally suited for a broad range of mobile computing devices, and particularly offers easy integration with POC, AVL, Power system industry, Elevator industry and M2M application.


General features
• LTE-TDD single-band:B41
• LTE-FDD Tri-band:B1/3/5
• Control via AT commands(GSM07.05,GSM07.07,V.25TER,GPRS,and LongSung enhanced AT commands)
• Supply voltage range 3.3V-4.2V
• Low Power consumption:  - Sleep mode: <3mA     - Power down <15 μA
• Dimensions: 24.0×26.0×2.5mm
• Soldering mounted type
• Temperature range : -40°C to +85°C



Specifications for data:

• Support Release 9 Category 1
• Up to 10 Mbps DL,5 Mbps UL



Interfaces:

• LCC package
- Power supply
- USIM 3V, 1.8V
- UART
- NET_STATUS
- IIC
- SGMII
- PCM
- RESET#
- POWER_ON#
- VOUT_2V85
- VOUT_1V8
- ADCs (1.8V tolerance)
- SPI
- USB
- GPIOs
-ANT_MAIN
-ANT_GNSS




Additional features:

• Embedded TCP/IP stack
• TTS
• EFS
• LongSung FOTA
• OpenCPU
• IPV4/V6
• Embedded/External SIM switching
• Multi partition protection


Approvals:
• RoHS/CCC/CTA


按文件类型搜索

  • A9500C PDF 2019-05-31
