A9500

Longsung A9500 is one of the smallest LPWAN modules in LCC castellation packaging with the compact size of 24.0 × 26.0 × 2.5mm, ultra low power consumption and extended temperature range.
Designed for use in any LPWAN network in the world. In eMTC network, A9500 enables connect to the Internet at DL data speed up to 512Kbps. In the area where eMTC service are not available, A9500 still enables reliable and secure data connect over NB-IoT/EGPRS network.

2205

分享
  • 产品概述
  • 产品特性
  • 相关下载

Longsung A9500 is one of the smallest LPWAN modules in LCC castellation packaging with the compact size of 24.0 × 26.0 × 2.5mm, ultra low power consumption and extended temperature range.
Designed for use in any LPWAN network in the world. In eMTC network, A9500 enables connect to the Internet at DL data speed up to 512Kbps. In the area where eMTC service are not available, A9500 still enables reliable and secure data connect over NB-IoT/EGPRS network.
To save space on the application platform, A9500 comes as an extremely slim and compact module. This makes it ideally suited for a broad range of mobile computing devices, and particularly offers easy integration with AMI, POS, , Intelligent Buildings and other M2M application.


General features:
• LTE-TDD Cat M1(eMTC) Single-band:B39
• LTE-FDD Cat M1(eMTC):B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B26/B28
• NB-IoT:B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B26/B28
• EGPRS Quad-band:B2/B3/B5/B8
• Control via AT commands:(GSM07.05,GSM07.07,V.25TER,GPRS,and LongSung enhanced AT commands)
• Supply voltage range 3.1V-4.2V
• Low Power consumption: - eDRX mode: <1.0mA    - PSM mode: <7μA
• Dimensions: 24.0mm×26.0mm×2.5mm
• Soldering mounted type
• Temperature range:-40°C to +85°C


Specifications for data:
• Cat M1 R13:Up to 1Mbps DL&UL
• Cat NB1 R13:Up to 200Kbps DL&UL


Interfaces:
• LCC package
- Power supply
- USIM/SIM 3V, 1.8V
- UART
- NET_STATUS
- PCM
- IIC
- RESET#
- POWER_ON#
- VOUT_2V85
- VOUT_1V8
- ADCs (1.8V tolerance)
-SPI
-USB
-GPIOs
-GNSS
- Antenna interface


Additional features:
• Embedded TCP/IP stack
• MQTT
• LWM2M
• UDP
• CoAP
• TTS
• LongSung FOTA
• OpenCPU
• Soft SIM



Approvals:
• RoHS/CCC/CTA/GCF/CE/PTCRB/FCC
